CHUG EQ-BOOST – Ultimate Tone-Shaping Boost Pedal

EQ BOOST ( Power supply not included )

US $229.00

Welcome your CHUG Life.
The EQ BOOST is the key to tweak your tone and gain with maximum precision and clarity.

US $229.00

SPECIFICATIONS

PEDAL TYPE Gain/Distortion
POWER CONNECTORS 5.33mm Barrel
POWER SUPPLY INCLUDED Not Included
POWER SUPPLY CPS9V500 (not included)
CURRENT DRAW 85mA
BATTERY None
INPUT JACK 1/4''
OUTPUT JACK 1/4''
WATTAGE n/a
GATE Yes
SPEAKER n/a
INPUT OHM 1 MΩ
OUTPUT OHM 260Ω
OUTPUT LEVEL 5 dBu
EQ Bass -Treb - Mid - Depth - Presence
BYPASS Buffered Bypass
TEST REFERENCE LEVEL 0 dBu = 0.775 Vrms
ADDITIONAL FUNCTIONS Input LF/HF Gain Filter
WEIGHT .06 kg. (1 lb.)
DIMENSIONS 120mm x 70mm (4.72 x 2.75 Inches )

Tested and Approved 3rd Party Power Supplies

BOSSPSA(XXX)S
DUNLOPECB-003
DIGITECHPS0913DC-01
VOODOO LABSPedal Power Series (9volts only !)

The EQ BOOST is the ultimate analog tool to articulately shape guitar tone while at the same time boosting your signal to smack the next stage of your signal chain. Taking inspiration from famous parametric equalizers that our favorite icons of metal made integral to their rigs, this pedal allows endless tweak-ability to achieve the sickest tones possible via high-pass filter, high frequency shelving and fully parametric midrange and bass controls. Level can be boosted or attenuated at each of the three bands and via separate input and output level controls with the LED changing color to indicate clipping. Cutting-edge modern circuit design delivers all these boost and EQ features with low noise specifications, unmatched clarity and is packaged in the same ‘iron-clad’ CHUG chassis as Solar’s other pedals. The EQ BOOST is effective in every configuration: In front of Amplifier – Inserted into FX loop of Amplifier – Any point of pedalboard signal chain – Before or after amp in box pedals and modelers – Before recording interface input & sounds amazing on Bass too!
